Detailed Results |
Dealer Transaction Mix |
Count |
Tx. Mix |
Failure Count |
Purchase |
12,229,040 |
25.00% |
1 |
Manage |
12,228,867 |
25.00% |
7 |
Browse |
24,464,433 |
50.01% |
0 |
Total # Dealer Transactions |
48,922,340 |
|
|
|
Manufacturing Transaction Mix |
Count |
Tx. Mix |
Failure Count |
CreateVehicleEJB |
14,245,237 |
50.00% |
1,697 |
CreateVehicleWS |
14,247,886 |
50.00% |
1,666 |
Total # Manufacturing Transactions |
28,493,123 |
|
|
|
Response Times |
Average |
Standard Deviation |
Maximum |
90th% |
Reqd |
Purchase |
0.064 |
0.08 |
4.338 |
0.130 |
2.000 |
Manage |
0.046 |
0.05 |
4.157 |
0.090 |
2.000 |
Browse |
0.077 |
0.09 |
3.564 |
0.150 |
2.000 |
CreateVehicleEJB |
0.268 |
0.19 |
6.762 |
0.450 |
5.000 |
|
CreateVehicleWS |
0.258 |
0.11 |
1.955 |
0.425 |
5.000 |
|
|
Reproducibility Run (SPECjEnterprise2010 EjOPS) |
21,509.68 |
|
|
Database Server HW (SUT hardware) |
Hardware Vendor: |
Oracle Corporation |
OS Vendor: |
Oracle Corporation |
Model Name: |
Oracle Server X5-2 |
OS Name: |
Oracle Linux 6 Update 5 x86_64 |
Processor: |
Intel Xeon processor E5-2699 v3 (Intel Turbo Boost Technology up to 3.6 GHz) |
Filesystem: |
ext3 |
MHz: |
2300 |
Disks: |
2x 300GB SAS-2 HDD, see notes |
# of CPUs: |
36 cores, 2 chips, 18 cores/chip, 2 threads/core (Hyper-Threading) |
Network Interface: |
4x 10GBit onboard and 2x 10Gbit Dual Port NIC |
Memory (MB): |
524288 |
Other Hardware: |
1x Sun 16Gb FC Dual Port HBA |
DIMM[0] Count: |
16 |
DIMM[0] Size: |
32768 |
L1 Cache: |
32KB I + 32KB D on chip per core |
# of Systems: |
1 |
L2 Cache: |
256KB(I+D) on chip, per core |
H/W Available: |
Mar-2015 |
Other Cache: |
45MB (I+D) on chip per chip |
OS Available: |
Dec-2013 |
|
Notes / Tuning Information |
Added to /etc/sysctl.conf:
fs.file-max = 6815744
fs.aio-max-nr = 1048576
kernel.shmall = 10737418240
kernel.shmmni = 4096
kernel.sem = 250 32000 100 128
net.core.netdev_max_backlog = 400000
net.core.optmem_max = 30000000
net.core.rmem_default = 30000000
net.core.rmem_max = 30000000
net.core.somaxconn = 40000
net.core.wmem_default = 30000000
net.core.wmem_max = 30000000
net.ipv4.ip_local_port_range = 9000 65535
net.ipv4.tcp_fin_timeout = 10
net.ipv4.tcp_max_syn_backlog = 30000
net.ipv4.tcp_max_tw_buckets = 2000000
net.ipv4.tcp_mem = 30000000 30000000 30000000
net.ipv4.tcp_rmem = 30000000 30000000 30000000
net.ipv4.tcp_timestamps = 0
net.ipv4.tcp_wmem = 30000000 30000000 30000000
net.ipv6.conf.all.disable_ipv6=1
net.ipv6.conf.default.disable_ipv6=1
net.ipv6.conf.lo.disable_ipv6=1
vm.zone_reclaim_mode=1
vm.nr_hugepages = 90000
vm.hugetlb_shm_group = 502
For each of the NICs:
set arp_announce = 2
set arp_ignore = 1
set txqueuelen 60000
enable tso and gso
4 Oracle listener processes were started, 2 processes bound per processor.
Bind each listener's network interrupts to its local processor.
Stop iptables.
Stop irqbalance.
External storage configuration:
1x Oracle Server X5-2L configured with 4x 1.6 TB NVMe PCIe SSDs,
2x 600GB Disks, and 1x Sun 16Gb FC Dual Port HBA for the database files.
1x Oracle Server X5-2L configured with 14x 600 GB disks, 1x Sun 16Gb FC
Dual Port HBA, and onboard PCI HW Raid controller for redo logs.
|
|
For questions about this result, please contact the submitter: Oracle Corporation
For other inquiries, please contact
webmaster@spec.org
- Benchmark run on Tue Mar 17 15:10:36 EDT 2015 by SPECjEnterprise2010 v1.03
- Result submitted on null
- Report generated by SPECjEnterprise2010 Reporter v1.00
Copyright © 2009-2015 Standard Performance Evaluation Corporation
First published at SPEC.org on 01-Apr-2015
