SPECjbb2005 SPECjbb2005 bops = 1001183, SPECjbb2005 bops/JVM = 58893
SGI Altix 4700 (17 Blade/34P DC)
BEA Systems BEA JRockit(R) 5.0 P26.4.0-10 (build P26.4.0-10-62459-1.5.0_06-20060529-2101-linux-ia64)

JVM run JVM Scores
158959
258864
358816
458847
559008
658834
758957
859087
958815
1058803
1158832
1258863
1358835
1458789
1558872
1659235
1758767
SPECjbb2005 bops = 1001183, SPECjbb2005 bops/JVM = 58893

Hardware
Hardware Vendor SGI
Vendor URL http://www.sgi.com
Model Altix 4700 (17 Blade/34P DC)
Processor Intel DC Itanium2 Processor 9050 1.6 Ghz
MHz 1600
# of Chips 34
# of Cores 68
# of Cores/Chip 2
HW Threading Enabled? No
Procs Avail to Java 68
Memory (MB) 139264
Memory Details 1 GB ECC DDR2 DIMMs (PC2-3200R) spread uniformly over 17 compute blades
Primary cache 16kBI + 16kBD on chip per core
Secondary cache 1024kBI + 256kBD on chip per core
Other cache 12MB (I+D) on chip per core
Filesystem xfs
Disks 1 x 146 GB SCSI (classes + OS)
Other hardware
Software
Software Vendor BEA Systems
Vendor URL http://www.bea.com
JVM Version BEA JRockit(R) 5.0 P26.4.0-10 (build P26.4.0-10-62459-1.5.0_06-20060529-2101-linux-ia64)
JVM Command Line numactl --cpubind=$node --localalloc java -Xms3840m -Xmx3840m -XXaggressive -XXcompressedRefs -XXthroughputCompaction -XXlazyUnlocking -XXtlasize256k -XXgcthreads8 -cp jbb.jar:check.jar spec.jbb.JBBmain -propfile SPECjbb.props -id $id
JVM Initial Heap Memory (MB) 3840
JVM Maximum Heap Memory (MB) 3840
JVM Address bits 64
JVM CLASSPATH jbb.jar:
check.jar
JVM BOOTCLASSPATH /tmp/jrockit-jdk1.5.0_06/jre/lib/ia64/jrockit/jrockit.jar:
/tmp/jrockit-jdk1.5.0_06/jre/lib/ia64/jrockit/managementapi.jar:
/tmp/jrockit-jdk1.5.0_06/jre/lib/managementapi.jar:
/tmp/jrockit-jdk1.5.0_06/jre/lib/rt.jar:
/tmp/jrockit-jdk1.5.0_06/jre/lib/i18n.jar:
/tmp/jrockit-jdk1.5.0_06/jre/lib/sunrsasign.jar:
/tmp/jrockit-jdk1.5.0_06/jre/lib/jsse.jar:
/tmp/jrockit-jdk1.5.0_06/jre/lib/jce.jar:
/tmp/jrockit-jdk1.5.0_06/jre/lib/charsets.jar:
/tmp/jrockit-jdk1.5.0_06/jre/classes
OS Version SuSE Linux Enterprise Server 9 SP3 (2.6.5-7.244-sn2)
Other software
Test Information
Tested by SGI
SPEC license # 4
Test location Mountain View, CA
Test date Aug 7, 2006
H/w available July-2006
JVM available June-2006
OS available Jan-2006
Other s/w available
AOT Compilation

Tuning
Operating system tunings
  • mount -t hugetlbfs nodev /mnt/hugepages
  • echo 340 > /proc/sys/vm/nr_hugepages
Notes
Command line options are described at http://e-docs.bea.com/jrockit/jrdocs/refman/index.html
System configured to use one JVM per NUMA node (4 cores).


JVM 1 Scores:
Warehouses SPECjbb2005 bops Incl. in metric
1 8629
2 29323
3 43139
4 59394 *
5 58760 *
6 59593 *
7 58945 *
8 58102 *
SPECjbb2005 (from 4 to 8) 58959 SPECjbb2005 bops
SPEC license # 4 Tested by: SGI Test date: Aug 7, 2006


JVM 2 Scores:
Warehouses SPECjbb2005 bops Incl. in metric
1 9061
2 29726
3 43721
4 58810 *
5 58784 *
6 59408 *
7 59136 *
8 58184 *
SPECjbb2005 (from 4 to 8) 58864 SPECjbb2005 bops
SPEC license # 4 Tested by: SGI Test date: Aug 7, 2006


JVM 3 Scores:
Warehouses SPECjbb2005 bops Incl. in metric
1 9506
2 29686
3 43738
4 58752 *
5 58855 *
6 59291 *
7 58984 *
8 58199 *
SPECjbb2005 (from 4 to 8) 58816 SPECjbb2005 bops
SPEC license # 4 Tested by: SGI Test date: Aug 7, 2006


JVM 4 Scores:
Warehouses SPECjbb2005 bops Incl. in metric
1 8127
2 29618
3 44043
4 59107 *
5 58664 *
6 59557 *
7 58987 *
8 57918 *
SPECjbb2005 (from 4 to 8) 58847 SPECjbb2005 bops
SPEC license # 4 Tested by: SGI Test date: Aug 7, 2006


JVM 5 Scores:
Warehouses SPECjbb2005 bops Incl. in metric
1 9284
2 29293
3 44021
4 59385 *
5 59314 *
6 59528 *
7 58865 *
8 57950 *
SPECjbb2005 (from 4 to 8) 59008 SPECjbb2005 bops
SPEC license # 4 Tested by: SGI Test date: Aug 7, 2006


JVM 6 Scores:
Warehouses SPECjbb2005 bops Incl. in metric
1 8222
2 29657
3 43037
4 58936 *
5 59094 *
6 59576 *
7 58751 *
8 57812 *
SPECjbb2005 (from 4 to 8) 58834 SPECjbb2005 bops
SPEC license # 4 Tested by: SGI Test date: Aug 7, 2006


JVM 7 Scores:
Warehouses SPECjbb2005 bops Incl. in metric
1 9672
2 29863
3 44083
4 59227 *
5 58954 *
6 59635 *
7 58931 *
8 58039 *
SPECjbb2005 (from 4 to 8) 58957 SPECjbb2005 bops
SPEC license # 4 Tested by: SGI Test date: Aug 7, 2006


JVM 8 Scores:
Warehouses SPECjbb2005 bops Incl. in metric
1 8263
2 29711
3 43166
4 59316 *
5 59200 *
6 59719 *
7 59045 *
8 58153 *
SPECjbb2005 (from 4 to 8) 59087 SPECjbb2005 bops
SPEC license # 4 Tested by: SGI Test date: Aug 7, 2006


JVM 9 Scores:
Warehouses SPECjbb2005 bops Incl. in metric
1 9527
2 29749
3 43987
4 59039 *
5 58998 *
6 59539 *
7 58578 *
8 57923 *
SPECjbb2005 (from 4 to 8) 58815 SPECjbb2005 bops
SPEC license # 4 Tested by: SGI Test date: Aug 7, 2006


JVM 10 Scores:
Warehouses SPECjbb2005 bops Incl. in metric
1 9156
2 29671
3 43223
4 58931 *
5 59221 *
6 59508 *
7 58303 *
8 58052 *
SPECjbb2005 (from 4 to 8) 58803 SPECjbb2005 bops
SPEC license # 4 Tested by: SGI Test date: Aug 7, 2006


JVM 11 Scores:
Warehouses SPECjbb2005 bops Incl. in metric
1 8019
2 29605
3 43356
4 59307 *
5 58757 *
6 59165 *
7 58953 *
8 57980 *
SPECjbb2005 (from 4 to 8) 58832 SPECjbb2005 bops
SPEC license # 4 Tested by: SGI Test date: Aug 7, 2006


JVM 12 Scores:
Warehouses SPECjbb2005 bops Incl. in metric
1 8139
2 29503
3 43674
4 59375 *
5 58888 *
6 59548 *
7 58558 *
8 57943 *
SPECjbb2005 (from 4 to 8) 58863 SPECjbb2005 bops
SPEC license # 4 Tested by: SGI Test date: Aug 7, 2006


JVM 13 Scores:
Warehouses SPECjbb2005 bops Incl. in metric
1 7215
2 29581
3 43917
4 58459 *
5 58928 *
6 59679 *
7 58941 *
8 58168 *
SPECjbb2005 (from 4 to 8) 58835 SPECjbb2005 bops
SPEC license # 4 Tested by: SGI Test date: Aug 7, 2006


JVM 14 Scores:
Warehouses SPECjbb2005 bops Incl. in metric
1 8908
2 29786
3 42978
4 58977 *
5 58561 *
6 59320 *
7 58952 *
8 58135 *
SPECjbb2005 (from 4 to 8) 58789 SPECjbb2005 bops
SPEC license # 4 Tested by: SGI Test date: Aug 7, 2006


JVM 15 Scores:
Warehouses SPECjbb2005 bops Incl. in metric
1 7886
2 29729
3 43045
4 59146 *
5 58773 *
6 59370 *
7 58932 *
8 58141 *
SPECjbb2005 (from 4 to 8) 58872 SPECjbb2005 bops
SPEC license # 4 Tested by: SGI Test date: Aug 7, 2006


JVM 16 Scores:
Warehouses SPECjbb2005 bops Incl. in metric
1 7767
2 29927
3 43426
4 59477 *
5 59406 *
6 59648 *
7 59097 *
8 58549 *
SPECjbb2005 (from 4 to 8) 59235 SPECjbb2005 bops
SPEC license # 4 Tested by: SGI Test date: Aug 7, 2006


JVM 17 Scores:
Warehouses SPECjbb2005 bops Incl. in metric
1 7762
2 29550
3 42941
4 58874 *
5 58789 *
6 59239 *
7 58829 *
8 58104 *
SPECjbb2005 (from 4 to 8) 58767 SPECjbb2005 bops
SPEC license # 4 Tested by: SGI Test date: Aug 7, 2006

SPECjbb2005 Version: [SPECjbb2005 1.07, March 15, 2006]
Reporting page, Copyright © 2005 SPEC. All rights reserved

First published at SPEC.org on 30-Aug-2006
