Hardware |
|---|
| Hardware Vendor |
Fujitsu |
| Vendor URL |
http://www.fujitsu.com |
| Model |
PRIMERGY BX620 S6, Intel Xeon X5670, 2.93 GHz |
| Processor |
Intel Xeon X5670 (Intel Turbo Boost Technology up to 3.33 GHz) |
| MHz |
2933 |
| # of Chips |
2 |
| # of Cores |
12 |
| # of Cores/Chip |
6 |
| HW Threading Enabled? |
Yes |
| Procs Avail to Java |
24 |
| Memory (MB) |
98304 |
| Memory Details |
12x8GB PC3L-10600R (CAS 9-9-9) |
| Primary cache |
32KB(I) + 32KB(D) on chip, per core |
| Secondary cache |
256KB(I+D) on chip, per core |
| Other cache |
12MB(I+D) on chip, per chip |
| Filesystem |
NTFS |
| Disks |
Seagate (2.5", SAS, 73GB, 10krpm) |
| Other hardware |
PRIMERGY BX900 S1 system unit as blade chassis |
|
|
Software |
|---|
| Software Vendor |
IBM Corporation |
| Vendor URL |
http://www.ibm.com |
| JVM Version |
IBM J9 VM (build 2.4, JRE 1.6.0 IBM J9 2.4 Windows Server 2008 amd64-64 jvmwa6460sr6-20090923_42924 (JIT enabled, AOT enabled) |
| JVM Command Line |
start /HIGH /AFFINITY [0xF,0x70,0x700,0xF000,0x70000,0x700000] /B java -Xaggressive -Xcompressedrefs -Xgcpolicy:gencon -Xmn1400m -Xms1875m -Xmx1875m -XlockReservation -Xnoloa -XtlhPrefetch -Xlp |
| JVM Initial Heap Memory (MB) |
1875 |
| JVM Maximum Heap Memory (MB) |
1875 |
| JVM Address bits |
64 |
| JVM CLASSPATH |
.\jbb.jar;
.\check.jar;
|
| JVM BOOTCLASSPATH |
C:\Program Files\Java\java\jre\bin\compressedrefs\jclSC160\vm.jar;
C:\Program Files\Java\java\jre\lib\annotation.jar;
C:\Program Files\Java\java\jre\lib\beans.jar;
C:\Program Files\Java\java\jre\lib\java.util.jar;
C:\Program Files\Java\java\jre\lib\jndi.jar;
C:\Program Files\Java\java\jre\lib\logging.jar;
C:\Program Files\Java\java\jre\lib\security.jar;
C:\Program Files\Java\java\jre\lib\sql.jar;
C:\Program Files\Java\java\jre\lib\ibmorb.jar;
C:\Program Files\Java\java\jre\lib\ibmorbapi.jar;
C:\Program Files\Java\java\jre\lib\ibmcfw.jar;
C:\Program Files\Java\java\jre\lib\rt.jar;
C:\Program Files\Java\java\jre\lib\charsets.jar;
C:\Program Files\Java\java\jre\lib\resources.jar;
C:\Program Files\Java\java\jre\lib\ibmpkcs.jar;
C:\Program Files\Java\java\jre\lib\ibmcertpathfw.jar;
C:\Program Files\Java\java\jre\lib\ibmjgssfw.jar;
C:\Program Files\Java\java\jre\lib\ibmjssefw.jar;
C:\Program Files\Java\java\jre\lib\ibmsaslfw.jar;
C:\Program Files\Java\java\jre\lib\ibmjcefw.jar;
C:\Program Files\Java\java\jre\lib\ibmjgssprovider.jar;
C:\Program Files\Java\java\jre\lib\ibmjsseprovider2.jar;
C:\Program Files\Java\java\jre\lib\ibmcertpathprovider.jar;
C:\Program Files\Java\java\jre\lib\ibmxmlcrypto.jar;
C:\Program Files\Java\java\jre\lib\management-agent.jar;
C:\Program Files\Java\java\jre\lib\xml.jar;
C:\Program Files\Java\java\jre\lib\jlm.jar;
C:\Program Files\Java\java\jre\lib\javascript.jar |
| OS Version |
Microsoft Windows Server 2008 R2 Enterprise |
| Other software |
N/A |
|
|
Test Information |
|---|
| Tested by |
Fujitsu |
| SPEC license # |
19 |
| Test location |
Paderborn, Germany |
| Test date |
Aug 5, 2010 |
| H/w available |
Jul-2010 |
| JVM available |
Nov-2009 |
| OS available |
Oct-2009 |
| Other s/w available |
N/A |
|
|
Tuning |
|---|
- Turned off "Hardware Prefetch" in BIOS.
- Turned off "Adjacent Sector Prefetch" in BIOS.
- Turned off "DCU Streamer Prefetch" in BIOS.
- Turned off "IP Prefetch" in BIOS.
- Turned off "Data Reuse Optimization" in BIOS.
- Each JVM instance was affinitized to 2 cores of a socket.
- Using the local security settings console, "lock pages in memory" was enabled for the user running the benchmark.
|
|
